p3 indoor fullcolor ledwall
cabinet size:768×768mm
Pixel pitch:6mm
Brightness:1000cd/m2
IP(wp):30
Consuption power:240W
Module size:192x192mm
  • Detailed
  • Parameter
  • Trait
  LED rental screen need to move frequently, repeated disassembly and installation, a simple understanding of "nice appearance, the installation of lightweight portable, stable and reliable quality", so the product shape design, structural design, material selection are stress, the main application In the enterprise, the meeting system, exhibition, hotel and other fields.
 Parameter name 参数 Parameter
 Pixel structure SMD
LED Specification 2121
 Pitch composing 1R1G1B
Pixel distance 3mm
Module resolution (W×H) 64×64dot
Module size 192mm×192mm
Pixel density 110000 dot
Peak power consumption 19W
Module weight 0.245Kg
White balance brightness 1000cd/m²
The best distance of visualization ≥ 3m
Horizontal perspective 120°
Vertical perspective 120°
 Luminance uniformity ≥97%
 Color uniformity ±0.003Cx,Cy
 Contrast 3000:1
 Maximum power 800 W/m²
 Average power 450W/m²
Input voltage AC220V(50Hz)
 Output voltage DC5V
Drive mode 1/16SCAN
 Frame frequency 60Hz
Refresh rate ≥1920 Hz
 Control way Synchronous control
 Typical life values 100000 hrs
 Working temperature range -10一40℃
 Storage temperature range -20一60℃
 Working humidity range (RH) 10-80%
 Storage humidity range (RH) 10-85%
